SFP Transceivers

CloudLight 25G SFP28 SR

Image required

The Lumentum CloudLight™ SFP28 SR is a SFP28 MSA compliance, low power consumption and lightweight solution for high-speed interconnect application over multimode fibers. The optical transceiver transmits 25G data in each direction up to 100 m with OM3 optical fiber.

Features

  • Bidirectional 25 Gbps operation
  • Supports 25 Gbps transmission distance up to 100 meters
  • Enabled by 850 nm VCSEL
  • Built-in CDR
  • Operating case temperature 0°C to 70°C
  • Single 3.3 V power supply
  • I2C management interface
  • Hot pluggable
  • RoHS-6 compliant
  • SFF-8431 compliant


Applications

  • 25G Ethernet
  • Datacom and telecom switch connectivity
  • Router backplane connections
  • High performance computing


Specification

  • Data rate: 25 Gbps
  • Supply voltage: 3.3 V
  • Power consumption: 0.6 W
  • Operating case temperature:  0°C – 70°C
  • Reach: 100 m with OM3
